SIM card holder 1.50mm high Nano Sim flip cover 6pin

category:Nano SIM Series
The number of clicks:
Release date:2018/10/31
Inquiry

details

Product ID:	XNT-0251AAAG06A
product name:	1.50mm High Nano Sim Flip Cap 6pin
specification:	Plastic: black high temperature UL94V-0; terminal: copper alloy; shell: stainless steel
Product Note:	Nano SIM Clamshell, Roll, 1500PCS/Reel, L14.0012.101.50
Product Category:	SIM microSim NanoSIM

Technical parameters:
1. Rated current: 0.5A AC / DC
2. Operating temperature: -20 °C ~ +60 °C
3. Storage temperature: -30 °C ~ +70 °C
4. Contact resistance: 100m ohms max.
5. Withstand voltage : 500V AC / 1 minute
6. Insulation resistance: 1000M ohms min./500VDC
7. Durability: 10000 times
8. Product temperature resistance: 260±5°C 10S
9. Flatness: 0.10mm MAX.
10. RoHS compliant
11. Stable and superior performance
Product Description:
1. This connector is widely used in mobile phones, tablet computers, navigators, LCD TVs, automobiles, aviation, smart wearable devices, etc.;
2. This product inspection process is: IQC feed inspection -> Storage -> pre-line self-test -> IPQC inspection -> FQC final inspection -> OQC cargo inspection
3. This product production process is: pre-line inspection -> Binder ribbon -> assembly nano sim Shell-->Card test-->Electrical test-->Remove test card-->Flatness test-->Positive test-->Appearance test-->FQC test-->Check in
